PCB Relay JQX-30F(T91) 24VDC 30A 5 Pin
50.00 EGP
Buy Now
Compare
Availability:
In Stock
SKU:ra-49
Specifications
- Model: JQX-30F DC24V T91
- Contact form: One open and one closed
- Theory: Electromagnetic Relay
- Contact form: 1Z
- Contact load:NO:30A/250VAC 28VDC
- Coil power: DC:0.93W, AC1.5VA
Specifications
| Contact Ratings |
1H |
1D |
1Z |
| Contact Resistance |
50mΩ (1A 24VDC) |
| Contact capacity |
7200VA/560W |
3600VA/280W |
4800VA/560W |
2400VA/280W |
| Insulation Resistance |
1000MΩ |
| Dielectric Strength |
BCC 2500VAC 1minute |
| 15ms / 10ms |
| Operate Time |
15ms / 10ms |
| Mount |
PCB |
Coil Power
| Nominal Coil Power |
DC:0.9W |
Coil Data
| Nominal Voltage VDC |
Pull-in Voltage VDC |
Release Voltage VDC |
Coil ResistanceΩ:±10% |
| 24 |
18.00 |
2.4 |
660 |
